GF2系列
- 性能参数图
机组款式 额定输出
(kw)额定电流
(A)燃油损耗率
(g/kw.h)起动方式 发动机机型 外形尺寸
(mm)净重.
(Kg)GF2-10KW 10 18.1 ≤258.4 12V D.C ELECTRIC 295D 1380x640x1000 600 GF2-12KW 12 21.6 ≤258.4 12V D.C ELECTRIC 295D 1380x640x1000 600 GF2-15KW 15 27.1 ≤258.4 12V D.C ELECTRIC 395D 1640x650x980 650 GF2-20KW 20 36.1 ≤258.4 12V D.C ELECTRIC 495D 1780x750x1000 750 GF2-24KW 24 43.3 251.6 12V D.C ELECTRIC 4100D 1780x750x1000 780 GF2-30KW 30 54.1 ≤258.4 12V D.C ELECTRIC 495ZD 1820x750x1000 920 GF2-40KW 40 72.2 ≤231 24V D.C ELECTRIC 4105ZD 2200x710x1350 1610 GF2-50KW 50 90.2 ≤224 24V D.C ELECTRIC 4105ZD 2280x820x1350 1750 GF2-64KW 64 115.5 ≤224 24V D.C ELECTRIC 6105ZD 2400x850x1400 1800 GF2-75KW 75 135.4 ≤224 24V D.C ELECTRIC 6105ZD 2400x850x1400 2330 GF2-90KW 90 162.5 ≤218 24V D.C ELECTRIC 6105AZLD 3000x900x1400 2500 GF2-100KW 100 180.5 ≤218 24V D.C ELECTRIC 6105AZLD 3000x900x1400 2650 GF2-120KW 120 216.6 ≤218 24V D.C ELECTRIC 6105IZLD 3000x900x1400 2800 GF2-150KW 150 270.7 ≤220 24V D.C ELECTRIC 6135AZD 3300x960x1650 3500 GF2-200KW 200 361 ≤220 24V D.C ELECTRIC 6135ZLDR2 3210x1320x1920 3750 GF2-250KW 250 451.2 ≤220 24V D.C ELECTRIC 6135ZLDU2 3210x1320x1920 3850 GF2-300KW 300 541.5 ≤220 24V D.C ELECTRIC J12V2DA 3300x1770x1905 4300 GF2-350KW 320 577.6 ≤220 24V D.C ELECTRIC J12V2DAX 3300x1770x1905 4350 GF2-350KW 350 631.7 ≤220 24V D.C ELECTRIC KTA19-G3 3400x1900x1900 4720 GF2-400KW 400 722 ≤220 24V D.C ELECTRIC KTA19-G4 3400x1900x1900 4950 GF2-500KW 500 902.5 ≤220 24V D.C ELECTRIC KT38-G 4336x1900x2310 7300 GF2-600KW 600 1083 ≤220 24V D.C ELECTRIC KT38-G2 4690x1800x2400 8300 GF2-800KW 800 1444 ≤215 24V D.C ELECTRIC KTA38-G5 4690x1800x2400 9200 GF2-1000KW 1000 1805 ≤215 24V D.C ELECTRIC KTA50-G3 5000x1900x2640 10600
